Cabezal de trípode fluido Seestar TH10

Desde $99.00

En stock - Listo para ser enviado

Modelo

Para una experiencia de compra fluida, tómese un momento para revisar nuestra Política de envío y entrega antes de realizar su pedido.

Disfrute de compras cómodas con envío global gratuito para pedidos superiores a $199. Para pedidos inferiores a $199, se aplicará un cargo de envío de $30.

El sitio está protegido con cifrado. Nuestra máxima prioridad es su seguridad y garantizamos que no compartiremos su información personal.

For existing TH10 owners: When pairing the TH10 with Seestar S50 Pro in EQ mode, we recommend purchasing the new Seestar TH10 3/8" Screw Quick-Release Plate for improved imaging stability.

Pagar con

  • Amazon
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

Su transacción está protegida con medidas de seguridad avanzadas para mantener su información confidencial

Cabezal de trípode fluido Seestar TH10

Cabezal de trípode fluido Seestar TH10

Desde $99.00

Desde $99.00

Seestar TH10 hydraulic tripod head is specially designed for use with Seestar smart telescopes in equatorial mode. It is also compatible with most SLR cameras, mirrorless cameras, video cameras, and more.

Made of durable full-metal construction, Seestar TH10 tripod head is compatible with most tripods and accessories on the market. It comes with a quick-release plate that supports both 3/8" and 1/4" screws.

With a self weight of 411g, this tripod head can carry a large payload of 5kg.

Note: The TC20 + S50 setup is not supported in regions with a latitude below 15° when used in equatorial mode.

Why Choose the Seestar TH10 Tripod Head?

  • Compact and Portable: Weighs only 411g
  • Hydraulic Damping System: Fluid and precise control
  • Wide Range of Shooting Angles: 360° pan & 180° tilt
  • Heavy Duty Payload: Supports up to 5kg
  • Broad Compatibility: DSLRs, mirrorless, camcorders

Appreciation Work

Compact and Portable

    Seestar TH10 is a compact hydraulic tripod head, with a height of just 84mm and a weight of only 411g. The base diameter is 50mm. Made from CNC-machined aluminum alloy, it offers a premium feel and enhanced durability, all while being incredibly lightweight. Perfectly designed for use with the Seestar smart telescope in equatorial mode.

Hydraulic Damping System

    Featuring an ergonomic hydraulic damping system, the Seestar TH10 tripod head makes polar alignment smoother than you expect. With just a light touch, you can easily adjust the pan and tilt scale, making it perfect for beginners!

Wide Range of Shooting angles

    Seestar TH10 tripod head supports 360° pan and -90° to 90° tilt, offering moderate damping for smooth adjustments and stable control. When used with Seestar, you can quickly calibrate the angles by the scale and switch to equatorial mode with a single click on the app. The intuitive knobs ensure secure locking, allowing for effortless multi-angle shooting. (360° Pan | -90° to 90° Tilt)

Wide Compatibility

    Seestar TH10 tripod head features a standard 1/4″ screw on top, compatible with most SLR cameras, mirrorless cameras, video cameras, and more, with an included adapter for 3/8″ screws, making it perfect for Seestar series. The base has a 3/8″ screw hole, ensuring compatibility with most tripods, monopods, and desk mounts. With a high load capacity of up to 5kg, it’s built to handle your equipment with ease.

Product Details

Método de conexión

Al utilizar el trípode TC20 del Seestar S50 con el cabezal TH10, tenga en cuenta que el cabezal podría golpear la pata en ciertos ángulos. Por lo tanto, esta combinación no es compatible con regiones situadas por debajo de los 15° de latitud.
Nota: TC20 es el trípode que viene con el Seestar S50.

1. Después de desplegar el trípode, ajuste cada pata a la longitud deseada y fíjelas firmemente. A continuación, coloque el trípode sobre una superficie plana y estable. Alinee una pata aproximadamente hacia el norte (en el hemisferio norte). Observe atentamente el nivel y ajuste la altura de la pata para asegurar que la burbuja esté centrada dentro del indicador circular. En este punto, el trípode está correctamente instalado.

2. Primero, instale TH10 atornillando el adaptador de tornillo roscado de 1/4″ a 3/8″ en el Seestar, luego use una llave de moneda para apretar los tornillos del adaptador.

3. Coloque la placa de liberación rápida, asegurándose de que encaje firmemente en el Seestar. (Vea las imágenes adjuntas como referencia). A continuación, apriete los tornillos de la placa de liberación rápida para asegurar una correcta alineación polar durante el proceso de instalación.

4. Apriete la perilla de ajuste horizontal en la parte inferior del TH10 y fíjelo al trípode. A continuación, afloje la perilla y mantenga la ranura de cola de milano orientada hacia el norte, que debe quedar alineada con la pata de soporte orientada hacia el norte. Finalmente, apriete la perilla.

5. Instale el dispositivo Seestar en el TH10, alineándolo con la ranura de cola de milano. Apriete la perilla firmemente para asegurar la fijación del equipo. Una vez confirmado, la instalación estará completa.
    Seestar TH10 hydraulic tripod head enables the Seestar S50 and S30 to operate in equatorial (EQ) mode. Note: When using the Seestar S50 in equatorial (EQ) mode with the TH10 tripod head and the TC20 tripod (included with the Seestar S50), please note that the equipment may collide with the tripod legs at certain angles. Therefore, this setup is not recommended for use in regions below 15° latitude.

Structural Dimension Diagram

What’s in the Box?

Product specifications

Product Name

Seestar TH10 Fluid Tripod Head

Material

Aluminum Alloy

Net Weight

411g

Max Load Capacity

5kg

Tilt Range

-90° to +90°

Base Mounting Angle

360°

Quick Release Plate

Supported

Quick Release Plate Screw

1/4" (with adapter for 3/8")

Base Screw Thread

3/8"

Range of Shooting Angles

360° pan & 180° tilt

Heavy Duty Payload

Supports up to 5kg

Compatibility

DSLRs, mirrorless, camcorders

Product specifications

Product Name

TC20 Carbon Fiber Tripod for Seestar

Net Weight

600g ± 30g

Load Capacity

30KG

Folded Length

265mm (screws not included)

Adjustable Height

235–365mm (screws not included)
